Re: Medfits - various ones...

Postby iak » Thu Mar 15, 2012 2:10 pm

The muck-up with couplings now having been resolved, the two stragglers are now await a door return spring on each side.
The unfitted beastie in the last post has had a trip to paint shop and has a nice crappy underframe paintjob; the bodywork has a bit of distressing to finish mind.
As for lettering, the PC gets assembled this weekend hopefully and then it is a Corel-Draw session or three drawing up transfers :?
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby iak » Tue Aug 14, 2012 12:21 pm

Oh no not some new images...


Archer Details in action here with a scratchbuilt door spring assembly.


Here is the full view of this beastie - more paint and lettering beckons



Grandt Line provide the detail here. A wee bit of dressing needed as well.


This image shows the Craig Welsh etches off wonderfully.
The tie bars, brake lever and lever guide all look fabbo to my eyes - the best around maybe?


An end view


The "... Beastie..." awaits :lol: :o :shock:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby MartinWales » Sun Aug 19, 2012 1:41 pm

Keep those images coming!

Need to reinvigorate the modelling mojo!
MartinWales

Posts: 896
Joined: Wed Aug 12, 2009 5:31 pm

Re: Medfits - various ones...

Postby iak » Mon Aug 20, 2012 2:49 pm

MartinWales wrote:Keep those images coming!

Need to reinvigorate the modelling mojo!


Stay tuned Martin.
There will be loads more :o :? :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby Richard Oldfield » Thu Aug 23, 2012 11:40 am

Hi Martin,

iak wrote:
Stay tuned Martin.
There will be loads more :o :? :lol:


Judging by the general scratching about, noodling and furtlement of four-wheeled stock on Iain's workbench at the club last night, I would anticipate there will be plenty to look at in the near future...............

Cheers,

Richard
Richard Oldfield

Posts: 1202
Joined: Mon Mar 01, 2010 8:08 pm
Location: Bidston near Birkenhead

Re: Medfits - various ones...

Postby iak » Thu Aug 23, 2012 1:32 pm

Sssssssssssssssh!! :lol: :lol: :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby MartinWales » Thu Aug 23, 2012 5:28 pm

Mmmmmmmmmmmm! :lol: :lol: ;)
MartinWales

Posts: 896
Joined: Wed Aug 12, 2009 5:31 pm

Re: Medfits - various ones...

Postby Davef » Thu Aug 23, 2012 8:41 pm

Ahhhhhhh.... huh, what?

:? :hmm: :drool

Dave F
Davef

Posts: 139
Joined: Mon Dec 06, 2010 10:45 am

Re: Medfits - various ones...

Postby iak » Fri Aug 24, 2012 9:08 am

:lol: :lol: :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby iak » Thu Aug 30, 2012 10:54 am

Lettering... :?
Drafting... :x
Software... :evil:
Paint... :o
Headache... :axe:

The endeavour nears its conclusion
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby iak » Mon Jul 22, 2013 11:01 am

Well finally some progress.
That is, of course, after a rather unplanned diversion health-wise....




Paint!! But the decals on the top one are going to be redone :axe:
They are half a midges widger too beeg! Me? Obsessive? :lol:


The above shows the early stages of finishing the insides of these beasties.
More will follow soon and it will NOT take 12 months ;)
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby stuartfwlr » Mon Jul 22, 2013 8:52 pm

Excellent stuff, glad your back reporting what progress you are making. Look forward to more updates.
stuartfwlr

Posts: 44
Joined: Fri Dec 17, 2010 12:17 pm

Re: Medfits - various ones...

Postby iak » Thu Oct 10, 2013 11:10 am

Morning all, progress at last!! :D
These b#gg#rs have taken far too bl**dy long so to post these images is a wee triumph!!

For your entertainment this morning:




The above medfits have been so long in the making and finishing its frankly embarrassing in some ways. Anyhow the finish line beckons so the correct lettering has begun

All of the decals I have drawn myself in Adobe Illustrator and then had printed on an ALPS printer. I still cannot decide which software I should stay with for this task. CorelDraw I have used for years, whilst Illustrator may be useful learning professionally so, why not take advantage there of .... :?:

More to come as I fight the good fight with decals and other naughtiness.....................
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby iak » Thu Nov 07, 2013 12:47 pm

AT LAST!! :shock:




The above three show the ALPS printed decals off I think.
The Electrification Warning sign is from the Railtec range - http://www.railtec-models.com/


Both of these two beasties are the auld Parkside Dundas kit, a kit which is unavailabe at this time I think and which may well be getting updated? I do hope so, because a lot of them ended up in the Engineers fleets.

It has been a long haul but finally, this project is nearing completion. Two down and four to go............. :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby iak » Thu Nov 07, 2013 2:08 pm

iak wrote:More progress on the above with some safety loops going on and some dressing.
These b*gg*rs will be finished before 2012!! :shock:


Hmmmm, strange what one finds in ones own threads??? :lol: :lol: :devil: :lol: :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby stuartfwlr » Fri Nov 08, 2013 10:30 am

Lovely stuff. You seem to have the knack for really bringing these things to life. It would be great if Parkside do update the kit, im sure we could all do with a few more of them :D
stuartfwlr

Posts: 44
Joined: Fri Dec 17, 2010 12:17 pm

Re: Medfits - various ones...

Postby iak » Fri Nov 08, 2013 11:39 am

stuartfwlr wrote:Lovely stuff. You seem to have the knack for really bringing these things to life. It would be great if Parkside do update the kit, im sure we could all do with a few more of them :D


Thanks Stuart ;)
One tries ones best, I just follow my instincts

As for Parkside? I REALLY want them to produce a newer kit, Mostyn could use a few more as well as myself...........
Mind, they maybe trying to develop a kit to do unfitted/fitted/retro-fitted?
We can but muse and cogitate :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby Pennine MC » Fri Nov 08, 2013 4:39 pm

I cant see Parkside bothering with a retool TBH, not with the ready availability of Mainline, Dapol and Bachmann RTR ones. Is the Ratio kit still available, cant say I've seen one lately?

The interior woodwork colour in that overhead shot is particularly nice 8-)
Pennine MC

Posts: 39
Joined: Mon Nov 28, 2011 6:37 pm

Re: Medfits - various ones...

Postby iak » Tue Oct 07, 2014 2:46 pm

The finished articles!!
After so much time wasted with darkness, illness and general malaise, getting these in service during the summer was a great release 8-)




Some close ups...

I am pleased with effect and finish here. Crud and muck lodged in places and the rusty end plate I think works?


This, I hope, captures a typical engineering stock lash job with regards to identification.


The venerable end of and auld, unfitted LMS medfit. Skanky and cruddy with some last vestiges of use.
The Electrification Warning notice decal has been mounted, as an experiment, on some plasticard to attempt to give some relief.
Pedantic? Wibble!!

I am still working on one last BR steel bodied Medfit and re-lettering a final LMS Medfit at the moment; then this project will be finished - finally! :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby MartinWales » Wed Oct 08, 2014 7:44 pm

Outstanding work on that weathered wood! Care to let us into the secret?
MartinWales

Posts: 896
Joined: Wed Aug 12, 2009 5:31 pm

Re: Medfits - various ones...

Postby Cock Sparra » Thu Oct 09, 2014 7:34 am

MartinWales wrote:Outstanding work on that weathered wood! Care to let us into the secret?



I have to agree with Martin outstanding piece of modelling and painting and weathering tips are always useful. :drool
Cheers Phil

I used to be normal but I'm better now
Cock Sparra

Posts: 327
Joined: Fri Oct 16, 2009 2:36 pm
Location: SUNNY DEVON?

Re: Medfits - various ones...

Postby Waveydavey » Thu Oct 09, 2014 8:06 am

Don't forget to paint, or otherwise tone down, the buffer shanks.

Only Dowtys and certain Oleos have shiny shanks, everything else should be unpainted iron or steel castings (I.e. Rusty)

Sorry but it's one of my pet hates.

Cheers

David
Modelling Clackmannanshire Railways in 1975
http://waveydaveysmodelmuddle.wordpress.com/
Waveydavey

Posts: 62
Joined: Mon Aug 17, 2009 9:36 am
Location: Under The Ochils Back In '75

Re: Medfits - various ones...

Postby iak » Thu Oct 09, 2014 8:56 am

It is one of mine to but after some of my health issues the past two years, just getting these beasties finished was a remarkable event... :oops: :o :lol:
Lets just say my time-managment gets a bit shoogly? :D
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Re: Medfits - various ones...

Postby MartinWales » Thu Oct 09, 2014 7:35 pm

But soooooooo well worth the wait!
MartinWales

Posts: 896
Joined: Wed Aug 12, 2009 5:31 pm

Re: Medfits - various ones...

Postby iak » Fri Oct 10, 2014 8:36 am

MartinWales wrote:But soooooooo well worth the wait!


Sláinte...

And I shall attempt to get my woody secrets up on here as welll - if you ken the meaning :lol:
Perfection is impossible.
But I may choose to serve perfection....
Robert Fripp


The only person who doesn't make mistakes is God and since he does not exist....


https://www.facebook.com/groups/PadgateWorks/
iak

Posts: 753
Joined: Thu Aug 27, 2009 11:34 am
Location: PADGATE WORKS IN DARKEST NORTH CHESHIRE...

Previous

Return to 1970s BR

Who is online

Users browsing this forum: No registered users and 1 guest

cron
